4K-8K Video Wall Controller
Image 180 degree rotation function,Edge shielding function,Image mapping function,Infrared remote control, chassis buttons, serial port control,Automatic recognition of EDID.Supports multiple input resolution point-to-point display modes, including 1×2, 2×1, 2×2, 1×3, 3×1, 1×4, 4×1, and up to 1×4 landscape display 7680×1080@60hz / 7680×1200@60hz 4×1 landscape screen 1920×4320@60hz / 1920×4800@60hz 1×3 portrait screen 5760×1080@60hz / 5760×1200@60hz 3×1 landscape screen 1920×3240@60hz / 1920×3600@60hz 2×2 landscape screen 3840×2160@60hz / 3840×2400@60hz…
SEND US A MESSAGE
Description
- Both HDMI and DP support 1×4（7680×1080@60hz）、4×1（1920×4320@60hz）、1×3（5760×1080@60hz）、3×1（1920×3240@60hz）、2×2（3840×2160@60hz）Point-to-point splicing, while also being backward compatible;
- Supports 1×2, 1×3, 2×1, 3×1, 2×2, 1×4, and 4×1 point-to-point splicing modes;
- 1 DP1.4 input and 1 HDMI2.0 input, with downward compatibility;
- Supports 1080P and 1200P output resolution options, compatible with LCD screens and resolution projection;
- Support automatic recognition of matching resolutions based on splicing patterns;
- Combined with multi head graphics cards, ultra-high resolution splicing walls can be formed, such as whole walls 11520×3240@60HZ etc;
- Support 180 degree flipping and edge blocking of any image;
- Supports infrared remote control, chassis buttons, and RS-232 control;
